I have designed a PCB using Autodesk Eagle.
After I routing the PC and check for errors from Tools -> Errors, there are lot of airwires (31) like below. But, I couldn't find any airwire.
How to solve this problem?
Asked
Active
Viewed 378 times
1
-
There's a ulp for that. Well, a 3rd party one. – Chris Stratton Dec 17 '19 at 05:36
-
Do you have layer 19 hidden? – Bruce Abbott Dec 17 '19 at 06:12
-
@BruceAbbott No. Its visible. – user_fs10 Dec 17 '19 at 06:19
-
@ChrisStratton Sorry. I didn't get it. – user_fs10 Dec 17 '19 at 06:20
-
1Try the hints given [here](https://www.element14.com/community/thread/56812/l/air-wire-problems?displayFullThread=true): rerun DRC, set the airwire colour to bright magenta, turn all layers off except the airwire layers – Huisman Dec 17 '19 at 07:16
-
Does this answer your question? [Finding air wires in Eagle](https://electronics.stackexchange.com/questions/34917/finding-air-wires-in-eagle) – Bruno Ferreira Dec 17 '19 at 19:42
-
@Bruno .. yes.that was the ansawer. EAGLE dosen't update errors real time. Need to check manually. – user_fs10 Dec 18 '19 at 15:07
1 Answers
3
After rerunning DRC problem is solved as @Huisman mentioned.
If you just select Tools -> Errors, It shows previous errors without updating current status.
Use Tools -> DRC... and click on the Check button to update the errors.
