I'm trying to understand why an ISFET needs a reference electrode. I have looked up several answers online but still dont understand. I have drawn out the doping, a MOSFET and the ISFET:

Mosfet Isfet In my mind, a change in pH changed the H concentration around the sensing pad which changed the properties of the channel?

TonyM
  • 21,742
  • 4
  • 39
  • 62
Leo
  • 251
  • 1
  • 8
  • Can you apply a gate voltage to the normal FET with only the + side of a battery? You need a reference, and that is what the reference electrode is for. It completes the circuit. – LukeHappyValley Sep 30 '19 at 10:00
  • Doesn't the accumulation of H+ due to low pH create an electric filed anyhow? I imagine that connecting only to the positive side of a battery would cause some electrons to move into the wire as they are attracted by the excess + charge. ? – Leo Sep 30 '19 at 10:15
  • @lukeHappyValley my intuition actually makes me think that I would still see an effect if I connected to only the positive terminal of a battery. – Leo Sep 30 '19 at 10:25
