I am currently designing a low power consumption and low phase noise VCO in ADS. But while performing the transient response I'm not getting the oscillating waveform in the output. I have attached the image of my circuit. Any help can be greatly appreciated.

]Circuit diagram

JRE
  • 67,678
  • 8
  • 104
  • 179
RUCHA KHANDARE
  • 11
  • 2
  • 1
    All the nodes say there's -333 MV on them, you might want to look at that first. Then, **after** your DC voltages are all OK, you should add something to start-up the oscillation. The simulator thinks that the static (non oscillating) state is a perfectly fine solution and theoretically that is true. In the real world **noise** would start the oscillation. During TRAN simulations, the simulator ignores noise so the oscillator doesn't start. To solve: add a pulse current source across the tank, make it output a short current pulse of for example 1mA after some delay, that will start it. – Bimpelrekkie Aug 13 '19 at 11:17
  • and have the current source turn on with a time much less than the oscillation period; thus for 1GHz oscillator, turn on with 100picoSecond. – analogsystemsrf Aug 15 '19 at 06:58
  • Thank-you for your reply. I have made changes in the design but yet there comes a problem because I don't know the parameters of BJT. Any idea how do I get the transistor parameters to make the design working . – RUCHA KHANDARE Aug 15 '19 at 11:53
