I am doing a study on Improvements in biasing and compensation of CMOS opamp.
Do you guys know how to come up with the equation for RDS4C ?
Asked
Active
Viewed 446 times
3
Marcus Müller
- 88,280
- 5
- 131
- 237
kevin998x
- 403
- 2
- 10
-
I think it would be useful if you showed what you tried. Where are you stuck? Do you know where to begin? Conductance is the reciprocal of resistance, that's for sure. And the circuit holds gm2E=gm4C. Now this conductance value must be for the conductance of the drain-source. – Daniel Tork May 05 '19 at 14:07
-
@DanielTork gm2E=gm4C ? Did you have a typing mistake or something else ? – kevin998x May 05 '19 at 14:19
-
I'm not sure what you mean. Please explain. – Daniel Tork May 05 '19 at 14:23
-
What do you know about your question that could be useful for solving it? – Daniel Tork May 05 '19 at 14:26
