Here is link with the picture of the fan:

enter image description here

The fan name is "ZALMAN ZM-F3(SF) 120MM ULTRA QUIET FAN"

I looked it up online, but I don't understand, I'm colourblind and it's difficult to distinguish the colors.

Charalampos Karamanlis
  • 1
  • 1
  • 2
  • We can take educated guesses, but it's impossible to know without knowing where that fan connected to! If it's just a PC fan, you can certainly look up "PC fan pinout" ;) – Marcus Müller Nov 23 '18 at 19:55
  • Well, the wires are black and white, so color isn't a problem. It's a PC fan, so look up how they are wire. That's a keyed connector, so you can find pin 1 if you match it to a drawing. – JRE Nov 23 '18 at 21:14
  • 2
    The linked (and closed) duplicate shows you the connections. You don't need the colors. Look at where the pins are in relation to the shape of the connector. – JRE Nov 23 '18 at 21:17

1 Answers1

1

Here is a nice black-and-white illustration that shows the pinout of

  • 3 pin connectors (so-called DC fans), to the left
  • 4 pin connectors (PWM controlled fans), to the right

PC fan header pinout

(Image from here.)

See also the duplicate post linked in the comments.
