I was reading a wiki article on Voltage doublers, and wondered - what are principal diffirences between two following schemes:

enter image description here

enter image description here

They all share same amount of components, but when and why should be one variant chosen over another?

1 Answers1

0

One difference is that in the first one, the output capacitor needs to be rated for the full output voltage. All of the other capacitors only need to carry half the output voltage.

Dave Tweed
  • 168,369
  • 17
  • 228
  • 393
  • So it's only about "capacitor rating" requirements? What do you think about circuit currents and coil/diodes operation? –  Sep 21 '18 at 11:57
  • What do *you* think about them? Perhaps you should try simulating both circuits. The simple simulator built into this site is perfectly adequate for this. What is the problem you're trying to solve here? – Dave Tweed Sep 21 '18 at 12:01
  • 1
    Theoretically? Exactly as i stated in the question. Practically?.. To determine few typical applications for each, with small comment on "Why first may fit it better than second (or vice versa)". E.g. i'm looking for smth simple, like "first scheme is used for this this and this because of following properties. Second scheme Is typically found in that and that, for that reasons." –  Sep 21 '18 at 12:12
