-1

I can't find SMD diode part no from Marking code,pls suggest if possible.enter image description here

Pradip Bharambe
  • 19
  • 3
  • thats because those codes generally say nothing much about it and are not meant for these identification purposes – PlasmaHH Jul 09 '18 at 09:54
  • How big is it ? – Tom Carpenter Jul 09 '18 at 11:55
  • Remove it from the board and try measuring the forward voltage drop – User323693 Jul 09 '18 at 17:41
  • sir it is SOD23 – Pradip Bharambe Jul 12 '18 at 04:00
  • @dim it is not necessary to mark this as a duplicate question, the link provided is related, but not a duplicate – Voltage Spike Jul 17 '18 at 20:36
  • @laptop Well, this question here is vague enough and yours is generic enough that I still think it can be considered a duplicate. Just like every vague question that looks like "Can I use a 5V/2A adapter instead of a 5V/1.5A" gets marked as a dupe to https://electronics.stackexchange.com/questions/34745/choosing-power-supply-how-to-get-the-voltage-and-current-ratings/34746. – dim Jul 18 '18 at 07:14

1 Answers1

0

My guess is: CMOZ43L in SOD523, marking R1 found here: https://www.centralsemi.com/get_document.php?cmp=1&mergetype=pd&mergepath=pd&pdf_id=CMOZ2L4_SERIES.PDF

BelaC
  • 1
