Name of the "object" next to an LCD

Question

I opened up a remote I had and saw there were two soft "objects" next to the display in it. What is it's name and function?

score 3 · Answer 1 · answered Feb 08 '18 at 08:51

3

Zebra strip. It connects the PCB to the display by having vertical conductive paths. The pitch between the conductive strips is finer than the spacing between the PCB pads so that it doesn't have to be aligned exactly. There are conductive contact areas on the glass LCD in the same pattern as on the PCB.

answered Feb 08 '18 at 08:51

Martin

8,320
1
22
30

Why is this answer downvoted? I can't see anything obviously wrong with it. – Dampmaskin Feb 08 '18 at 09:13
@Dampmaskin probably because it answers a question which is a duplicate. – Arsenal Feb 08 '18 at 09:21
And the question still has zero votes. Oh well. Not everything is for me to understand I guess. – Dampmaskin Feb 08 '18 at 11:09
