I'm trying to repair Black and Decker Thermal Leak Detector. I was testing the 9v input from the battery when I notices the chip was cracked. I'm thinking it is a transistor, but I haven't been able to cross reference it. Any help would be grateful.enter image description here

Tom Rasmussen
  • 19
  • 1
  • Sorry, component U1 – Tom Rasmussen Jan 07 '18 at 00:59
  • U1 usually designates an IC ... transistors are usually Q1 ... but the manufacturer may have decided otherwise ... a schematic would be helpful. .... please add information about the model number to your question .... do not add info to comments as you have done above – jsotola Jan 07 '18 at 01:04
  • http://www.s-manuals.com/pdf/datasheet/b/g/bga6289_nxp.pdf – G36 Jan 07 '18 at 01:05
  • @G36 given the context that this is from a drill a microwave part seems rather unlikely. – Peter Green Jan 07 '18 at 01:15
  • Looks like they decided to save a penny and left out the reverse battery protection. Chances are this is a voltage regulator (linear or switching) but it's hard to tell from the part number. – Spehro Pefhany Jan 07 '18 at 01:26
  • @PeterGreen It's an IR thermometer by the looks of it. No microwaves. – Spehro Pefhany Jan 07 '18 at 01:27
  • @TomRasmussen Related: https://electronics.stackexchange.com/questions/334128/how-do-i-identify-smd-components-or-any-component/334129#334129 – Voltage Spike Jan 07 '18 at 04:02
