I'm using an LM358 op-amp for unity gain (feedback to V-). However, I'm getting some unexpected results. When Vin is from 0v - 3.75v, op-amp output is as expected 0 - 3.75v. However, when Vin is greater than 3.75v, op-amp output is capped at 3.75v, even though Vcc is 5v. Can someone help shed some light to why op-amp unity gain can be less than 1?

Op-amp sch

LM358 datasheet can be found here: http://www.onsemi.com/pub/Collateral/LM358-D.PDF

dlcircuits
  • 53
  • 4

2 Answers2

11

It's right there on page 4:

Output Voltage−High Limit (VOH): VCC = 5.0 V, [...] | 3.3 | 3.5 | - | V

Ignacio Vazquez-Abrams
  • 48,282
  • 4
  • 73
  • 102
6

The LM358 isn't rail-to-rail. The output cannot be driven to Vcc.

Mike
  • 247
  • 2
  • 10
