How do I use a L297 IC?

Question

I'm considering purchasing a L297 IC to drive my unipolar motor, but when I look at the datasheet here , I can't make any sense of it. I've been working with an L293D, which makes a lot of sense because it has the logic supply, the enable pin, the power, outputs matched with inputs, etc. However, when I looked at the diagram, I couldn't figure out where to place the 4 coil wires and the common wires, and how to hook it all up to my Raspberry Pi. Any help would be appreciated.

You can't directly drive a motor with that chip. Does that help ease your pain? — Andy aka, Jul 26 '17 at 17:25
I am pretty sure a 3-word query on google would resolve your problem. — Eugene Sh., Jul 26 '17 at 17:25
If you look at the diagram on the front page of the datasheet you provided a link to you would see that it is not designed to drive the motor directly and needs a companion part such as the L298. — Kevin White, Jul 26 '17 at 17:33
@Andyaka yes that's actually exactly what I was wondering thank you very much — NeonCop, Jul 26 '17 at 17:58
@NeonCop Please write specific questions, a good specific question will generate good answers — Voltage Spike, Jul 27 '17 at 17:27

score 1 · Accepted Answer · answered Jul 26 '17 at 17:51

I'm considering purchasing a L297 IC to drive my unipolar motor, but when I look at the datasheet, I can't make any sense of it.

The first clue to what the L297 does is on page 1 of the data sheet: -

The L297 can be used with monolithic bridge drives such as the L298N or L293E, or with discrete transistors and darlingtons.

The second clue is the picture below: -

Notice how it interfaces to the motors via the fairly crappy L298.

If you are intent on using it may I draw your attention to this Q&A. It might contain useful information should you be thinking of using the L298 driver.
