I just opened up an old piece of electronics. While salvaging, I found a board with this waxy stuff on it? What is this and what is its use?

A Picture of the Board

P.S. The substance I am talking about is the lightly tanned wax on the top right of the board.

MetricSystemAdvocate
  • 696
  • 2
  • 7
  • 19
  • 1
    Out of curiosity: What is that device you're salvaging from? – Eric Seastrand Jul 14 '17 at 17:28
  • Please be explicit as to which substance you mean. There are at least two substances in the image which I can interpret your question as referring to. I would suggest using a hand dawn red circle in the image to explicitly indicate what you are talking about. Presumably you mean the light tan colored substance in the upper-right of the enclosure. That is the substance which is discussed in your highest voted answer. I think the other non-negative answer is talking about the blue substance in the tune-able coil in the bottom center of the PCB. – Makyen Jul 15 '17 at 02:34
  • it is from an old TV sharpness controller. – MetricSystemAdvocate Jul 15 '17 at 06:59
  • Not just old stuff. See https://electronics.stackexchange.com/questions/191024/are-we-still-protecting-pcbs-with-wax – Paul Uszak Jul 15 '17 at 12:26

2 Answers2

21

Am guessing that the wax-covered part of the circuit is a radio-frequency oscillator. The coil of wire has been hand-tuned by spreading its turns so that the oscillator frequency matches up with other (transmitting? receiving?) equipment. The wax stabilizes this coil so that it doesn't shift frequency.
Disturbing the wax can de-tune the oscillator.

glen_geek
  • 23,591
  • 1
  • 22
  • 50
1

It's wax. It was applied on the assembly line in order to 'nail down' an iron ferrous core in an inductor coil in some highly critical valued circuit I wager.

StarBaseONE2
  • 11
  • 1
