I want to know how an AC electric magnet works since the polarity of an AC current changing 100 times in each second (for 50Hz mains supply) so its magnet polarity(N & S) also will changed 100 times in each second. But i see AC solenoid always moved in one direction when the power is connected, why?

M.A.K
  • 1,838
  • 5
  • 26
  • 43
  • 7
    Iron sticks to N pole. Iron sticks to S pole. Iron sticks to NSNSNS ac pole. – wbeaty Feb 24 '17 at 21:14
  • @wbeaty, wouldn't the zero crossings potentially create a hazard in some applications? Such as with strong electro-magnets used to lift heavy steel objects? – user57037 Feb 25 '17 at 17:49
  • 2
    An AC electromagnet will gain and lose its magnetic pulse at two times the line AC frequency. If it's strong enough it will come back on so quickly that it can pick up the falling iron object. @mkeith: The zero-crossings alone shouldn't be dangerous. If the magnet is too weak it won't pick up heavy objects in the first place. If it buzzes loudly, it may be a sign that just a small dip in voltage will make it drop something heavy. – Oskar Skog Feb 25 '17 at 17:52

1 Answers1

11

A solenoid core isn't a magnet itself but instead a simple iron piece. Such an iron piece "gathers" the magnetic field lines which come from the coil. When the iron core is not centered inside the coil, the magnetic field lines are longer than they could be, which results in a force to change that.

Solenoid, iron core, field lines

a) coil without core → field lines long and wide. High magnetic resistance.

b) core not entirely in the coil → field lines shorter and "gathered" into the core as the magnetic resistance is lower there.

c) core centered in in the coil → field lines shortest and a bigger part of it running in the core so magnetic resistance is even lower than in b)

That's the reason why the core is moved into the coil. Because when it's centered inside the coil, the field lines are shorter and magnetic resistance is much lower. As this doesn't depend on field direction, an iron core is always moved into the coil, making it work with both AC and DC applied to the coil.

Janka
