I'm trying to make my STM32 communicate VIA Can. Therefore I'm making use of the CAN transceiver MCP 2551. In many circuits I've seen a 100 nF between Ground and Vdd. What is the reason for that? Here an example:Example schematic showing a MCP2551 with 100nF capacitor between VDD and VSS

try-catch-finally
  • 1,254
  • 3
  • 19
  • 37
cylex
  • 79
  • 2
  • 6
  • 4
    This is just a decoupling (bypass) cap. See http://electronics.stackexchange.com/questions/2272/what-is-a-decoupling-capacitor-and-how-do-i-know-if-i-need-one/2278 also: http://electronics.stackexchange.com/questions/15135/decoupling-caps-pcb-layout/15143 – dim Dec 19 '16 at 21:13

1 Answers1

2

It's called a decoupling or power supply bypass capacitor. It's used to reject noise from the supply pins of an IC.

calcium3000
  • 2,484
  • 1
  • 14
  • 41
  • Ok thanks! How do I determine which capacity is needed for a decoupling capacitor? – cylex Dec 19 '16 at 21:23
  • Dig around dim's links for some good suggestions and explanations if you're curious, but the most common (that I've seen) is 0.1uF. – calcium3000 Dec 19 '16 at 21:29
