14

VSC7145XRU-31/C - this IC uses PQFP package

the replacement component for that TLK2201 uses HVQFP package

also TLK2541 uses TQFP

that's why i wanted to know whats the clear difference between them

stevenvh
  • 145,145
  • 21
  • 455
  • 667
K S K Chaitanya
  • 141
  • 1
  • 1
  • 3

1 Answers1

11
  • VQFP - Very Thin Quad Flat Pack. Around 0.8 mm thick.
  • HVQFP - Heatsink Very thin Quad Flat Pack. Also around 0.8 mm.
  • TQFP - Thin Quad Flat Pack. Typically 1mm thick.
  • LQFP - Low-profile Quad Flat Pack. Typically 1.4 mm thick.
  • PQFP - Plastic Quad Flat Pack. Thickness from 2 mm up-to 3.8 mm.

Since you were interested in HVQFP, here's an image from Digikey. This one allows you to mount a heatsink at the top for better dissipation. enter image description here
