I know that technically there is little difference between AC or DC heating of the tube - if it gives proper voltage everything is fine... Except the hum: I have read in various sources that some preamp tubes are very resistant to AC hum and can be properly heated with it and some are somewhat terrible with the hum and are needed to be heated with filtered DC if you want to achieve noiseless performance.

The question is.. How do we know which types of tubes are affected by the hum and which are not? Can you find out without testing? I have researched various datasheets but found little help.
The problem it appears is that in most datasheets it is not stated if the heater is isolated or not. (Obviously an isolated heater will produce way less hum)

I plan on working with ECC85 tube (similar but not the same as 12AT7/ECC81). (Maybe some of you had experience with this specific tube?) In this tubes datasheet it is stated that it can be heated with both AC and DC but then again... if we are working on somewhat high-end headphones amplifier is the noise going to be an issue with AC heating? And how bad is it going to be? Here is the datasheet: https://frank.pocnet.net/sheets/010/e/ECC85.pdf

There is a wonderful source of information in this website (tubes enthusiasts - you must read this! It's a gold mine) and it basically answers my question (use DC and you can not go wrong). http://www.valvewizard.co.uk/heater.html

Of course you can always go the guaranteed road and filter AC to DC (cmon, it's easy isn't it?) but I am really curious whether you always need DC heating for high end performance... And how do you find it? - the answer is still somewhat a mystery to me.

enter image description here

Giedrius
  • 365
  • 1
  • 8
  • 25
  • I think you are putting way too much energy into this. If you have any concerns then just use DC for all the tube heaters!! For a purist tube application you may want to consider using tubes for the AC to DC rectifier too. – Michael Karas May 25 '16 at 13:49
  • Yes, I agree - I am putting too much energy as you say into this. The best way to find out would be to simply test with AC and if there are some problems go to DC. Easy as that.. But curiosity defeats - I am simply really curious what experience people had. And the more you know - the more experience you have yourself! – Giedrius May 25 '16 at 13:53
  • Be aware that insufficiently rectified AC current can cause a way more hum than a 50Hz sinus. – greg May 25 '16 at 13:53
  • *whether you always need DC heating for high end performance* I would think that it will help to feed the heaters with DC but that it is not needed. You could use a circuit where feedback (yuck, feedback ;-) ) suppresses the hum or choose the potential of heater and kathode carefully. There might be other ways as well. Maybe some "high end" amplifiers are only "high end" because they hum a little. It could be part of the "tube" sound ! – Bimpelrekkie May 25 '16 at 13:53
  • Hum is never a part of the sound! Most audiophiles would give horrible reviews if they bought a tube headphone amplifier and it would hum. On the other hand - distortions* are part of the 'tube' sound :) – Giedrius May 25 '16 at 13:55
  • Why not use a solid-state regulator for the filaments? The arrangement you show will shorten the life of the tubes if the capacitors are big enough to smooth the full-wave rectified AC out (voltage about 7.7V) and if you're less than rated current on the filament transformer probably more. – Spehro Pefhany May 25 '16 at 13:57
  • You can use a regulator but I fear adding too many parts. By that I mean that the more I add, the more hassle I have and the more space it takes (and it wastes power too so I have to put a bigger transformer). I would not worry too much about tube life as most of them will last **at least** 2 years. And this is with everyday use. By the way, lower voltages are 'better' for tube preamplifiers as they do not burn out so quickly, so actually.. it would be 'healthier' for them to at lower voltage than specified. (at least that's what I read) – Giedrius May 25 '16 at 14:13
  • 2
    The datasheet says these tubes got indirect heating, therefore they may be heated with AC current. – Uwe May 25 '16 at 14:19

1 Answers1

3

Hum caused by the indirect heater system is due to the diode effect between the filament and the cathode. Modern tubes (ie post WW2) have a special insulation that prevent filament’s space charge to appear but it can't be completely eliminated. Since cathodes are often positive in regard to the filament, this sets the diode in the non blocking way hence creates an electron flow between heaters and cathode which causes hum if the filaments are heated with AC.

Fixing the potential of the heaters at +15V above the cathode instead of fixing it to the 0V (or ground) sets the resulting diode as non passing hence prevent any noise.

I do complete a bit my answer. Unless the signal amplified by the tube is in the range of mV (like a guitar speaker signal), the noise created by the diode effect with AC filaments is insignificant. It is not the case in mic amplifiers or RIAA stages.

greg
  • 433
  • 3
  • 6
  • So from what I understand if we are using a line signal (audio from a mp3 player as an example) the hum level is going to be truly insignificant and unnoticeable? And if we are using a weak signal (guitar) DC heating would be better off and give better results? – Giedrius May 25 '16 at 15:00
  • As I stated in the comments above, filtering heaters voltage is hard due to the high current they need (often more than 1A). Insufficient filtering creates a ripple with strange waveforms that can cause more hum than it actually heals. If you experience hum and you know it is caused by the heater system (they are lot of hum sources out there), try to set heaters potential above the tubes cathodes before going for redressing heaters voltage. – greg May 25 '16 at 15:07
