I have subcircuits of a solar cell (resistors and diodes) in LTSPICE. I want to connect the solar cells (sub-circuits) together. However, each solar cell has a different temperature. I can set the temperature of the program with .Temp but how can I change the temperature of each sub-circuit separately.
Asked
Active
Viewed 1,708 times
6
Hamed
- 311
- 1
- 2
- 10
1 Answers
6
There are a few ways.
You can add it to the actual model you are using as a final parameter or use the component dialog box:
To get this dialog for anything that has a .model statement, use CTRL + right click.
If you are adding the temperature command within the SPICE listing, it needs the format of "temp=xx"; no dot required. The listing you show has omitted the '='.
Peter Smith
- 21,923
- 1
- 29
- 64
-
Dear Peter, thank you for your answer. I tried this method but it does not work (why?). I have uploaded the picture of the circuit and netlist in addition to the change you mentioned. Since I have diodes in my model, by changing the temperature, I expect to have reduction in my open-circuit voltage. However, the open-circuit voltage does not change. Is there any mistakes there? I add the code picture to the main question. Greets and thanks in advance – Hamed Apr 18 '16 at 12:16
-
The answer has been updated with the required syntax for embedding within a .subckt statement. – Peter Smith Apr 18 '16 at 12:46
-
Dear Peter thanks for your answer. The .temp command is for the total circuit and the dialog that you see beside the commands is for the sub-circuit. I have written it without dot (.). – Hamed Apr 18 '16 at 13:19
-
Even without using .temp command, the results do not change. – Hamed Apr 19 '16 at 11:21
