I'm designing a circuit requiring MMCX board edge connectors, specifically using the Molex 73415-0961 jack. When looking through the datasheet for suggested PCB layout, I see mention of an additional optional feature. But there's no mention of purpose for this option and I'm curious what it's designed for.

Here's a screenshot of the layout with the optional feature highlighted: Molex 73415-0961 PCB layout with optional feature

bitsmack
  • 16,747
  • 9
  • 52
  • 108
Kjon VALIS
  • 73
  • 3

1 Answers1

7

That is a rectangular piece of soldermask used as a "solder dam". It is used in cases where the microstrip ("rf trace") doesn't have a soldermask coating.

During assembly, solder paste is applied to the exposed pads under the connector. But if the microstrip isn't covered with soldermask then the solder will flow along the microstrip. This makes for a bad solder joint, and also will change the characteristic impedance of the microstrip.

The solder dam simply acts as a barrier to keep the solder where it belongs.
