What kind of circuit is it (negative voltage generating)?

Asked Feb 21 '16 at 09:23

Active Feb 21 '16 at 23:48

Viewed 496 times

5

What is the name/type of this negative voltage-generating circuit?

Enter image description here

edited Feb 21 '16 at 23:48

Peter Mortensen

1,676
3
17
23

asked Feb 21 '16 at 09:23

user79839

145
3

2 Answers2

9

Polarity-inverting buck-boost is what it is called.

answered Feb 21 '16 at 09:32

Spehro Pefhany

376,485
21
320
842

1

This is a Buck-Boost converter.

answered Feb 21 '16 at 09:32

Mario

8,145
1
14
19
