I was looking for a SMD diode to add reverse-polarity protection to a circuit I was designing, and the PMEG3020CPA looked like a good fit with regards to my current and voltage needs.

What confused me is why the data sheet shows two anodes, so I have a few questions about that:

  1. Are the two anodes meant to be connected? E.g. the two internal diodes would be in parallel. Or should only one be used?
  2. Are the current and voltage ratings given for each of the internal diodes, or both together?
  3. Why is it designed or diagramed like this?

I ran into this question about three-terminal diodes but that seemed to be one diode and a floating third pin, which isn't really relevant.

Community
  • 1
Trevor Gross
  • 258
  • 3
  • 10

1 Answers1

12

It's a dual diode. There are two diodes in one package.

enter image description here

You can parallel them if you want (connect 1 and 2) but there is no matching characteristics given, so you can't really depend on the rating to be much better, and the leakage will definitely double.

The characteristics are for each device, however they are (obviously) tightly thermally coupled so the total power dissipation will have to be taken into account.
