i am trying to map this schematic onto a virtual breadboard but i dont understand what the 10k potentiometer symbol represents. am i supposed to connect the 5v terminal to the positive end of a battery and 0v to negative end. The virtual potentiometer also has three pins with the middle one labeled wiper while the other two named as terminals so where do i connect the pins?

enter image description here

J. Doe
  • 97
  • 1
  • 9
  • 1
    Physically, that's a resistive track with 10k end-to-end (the box) with a wiper that slides along the track (the 3rd terminal on the side of the box). You can also think of it as two resistors A and B where A + B = 10k and the ratio changes. How to simulate that is up to you. – AaronD Nov 25 '15 at 18:19
  • @AaronD so do i connect pin 5 to the wiper? – J. Doe Nov 25 '15 at 18:27
  • 1
    The schematic shows pin 5 connected to the wiper. – Peter Bennett Nov 25 '15 at 18:36
  • 1
    Yep. (15 char minimum) – AaronD Nov 25 '15 at 18:36
  • 1
    I'd be more worried about that wire from the flip flop to the motor if i were you. – Andy aka Nov 25 '15 at 21:44
  • 1
    @AndyAka is this a PWM controller for a RC servo? in which case the *motor* is actually a three terminal servo – Icy Nov 26 '15 at 09:04
  • 1
    Possible duplicate of [Connecting a potentiometer](https://electronics.stackexchange.com/questions/120727/connecting-a-potentiometer) – Rev Mar 09 '19 at 10:05

1 Answers1

1

A potentiometer has 3 terminals, and physically consists of a resistive track with terminals at either end and a moveable 'wiper' terminal that can be positioned anywhere along the track.

A typical use for a potentiometer is as a variable voltage divider, and this is how it is being used in your circuit. 5V is presented across the length of the track (at the terminals), and so the voltage at the wiper can be altered to give any voltage value in this range.

Potentiometers are usually drawn as a fixed resistor (the track) with an arrow representing the wiper positioned somewhere along its length. The one in your diagram is simply missing its arrow head. So yes, you connect the wiper to pin 5 of your IC, one of the track ends to GND and the other to 5V (which is also the supply to your servo, and is presumably the same as Vcc supplied to the IC)
