Is it possible for the base current to exceed the collector current for a BJT in saturation mode? (If the base current was increased without the collector current increasing at all)
Asked
Active
Viewed 263 times
1
-
Certainly possible. At some point, the Vce(sat) will stop decreasing and will begin to increase as the base current increases (for a given collector current), so it's not something that is necessarily useful. – Spehro Pefhany Feb 19 '15 at 18:45
-
@SpehroPefhany How does it happen? – Undertherainbow Feb 19 '15 at 19:24
-
The base-collector junction is forward biased in saturation- so current does not just flow to the emitter, but also to the collector. – Spehro Pefhany Feb 19 '15 at 19:40
2 Answers
3
It is possible. Consider the figure below.
The collector current at saturation will be $$I_{Csat} = \frac{V_{CC}-V_{CEsat}}{R_C} \approx \frac{V_{CC}}{R_C}$$
The base current is given by, $$I_B = \frac{V_{CC} - V_{BE}}{R_B} \approx \frac{V_{CC}}{R_B}$$
So it is clear that the currents at saturation are entirely decided by the resistors and hence base current can be greater than the collector current at saturation.
nidhin
- 8,197
- 3
- 28
- 46
3
Yes, it is obvious that the base current can exceed the collector current if you consider the limiting case where the collector is open-circuit. The collector current will be 0, but you can still drive from 0 to the maximum allowed base current thru the base. With the collector open, base to emitter just looks like a diode.
Olin Lathrop
- 310,974
- 36
- 428
- 915
