What should I do with the unused diode in the SOT-323-3 (SC-70-3) package?

Asked Oct 30 '14 at 20:47

Active Oct 30 '14 at 20:47

Viewed 306 times

enter image description here

I'm planning to use one of this diode in my circuit. But the package contains two of them. I chose it mainly because of its 3ns reverse recovery time. How do I use them in my circuit?

I have three options in my mind if you won't suggest a forth one.

Use one, leave the other open.
Connect them parallel.
Use one, connect the unused device pin to a rail with a very large resistor.

How do I get the best switching characteristics?

asked Oct 30 '14 at 20:47

hkBattousai

13,913
31
114
190

1

I was going to say option 2 until I read that you chose the part for its RR. – Ignacio Vazquez-Abrams Oct 30 '14 at 20:54
5

4. Use one and short the unused anode to the cathode. – brhans Oct 30 '14 at 20:58
1

Yep, I was just about to mention that. – Ignacio Vazquez-Abrams Oct 30 '14 at 20:59
@brhans Why don't you post it as an answer along with a little explanation? – hkBattousai Oct 30 '14 at 21:02
3

Make sure that you use the diode on the left, so that you can substitute the single-diode part. (which seems to be more widely available than common-cathode anyway.) – markrages Oct 30 '14 at 21:30
Get an x-acto knife, cut one diode out, and post it to me. I'll make use of it. – Majenko Oct 30 '14 at 21:31
wiring diodes in parallel is generally not a great idea (thermal runaway and so on), but maybe they are very well matched since their probably on the same die... – vicatcu Oct 30 '14 at 23:26
@vicatcu Thermal runaway is not an issue here since only one of them are enough capable of carrying the current. – hkBattousai Oct 31 '14 at 03:54
