I need to figure out how to physically mount the following AC-DC converter to a PCB to be used as part of a regulated power supply. The pin height is min 3.0 mm.

Should I mount it as a through-hole component, a surface mount component, or have a header that this component is plugged into?

ACD
  • 2,338
  • 11
  • 26
Brown1
  • 67
  • 5
  • 2
    They are normally mounted as a through hole component. The style of component is known as a "Hybrid". – Majenko Oct 01 '14 at 12:36
  • Note, this is a perfectly fine question as it follows the site's rules entirely. No need to apologize. – Dzarda Oct 01 '14 at 12:53

1 Answers1

6

Shown on their datasheet is this picture on page 3:

enter image description here

The recommended footprint is for through-hole mounting and it is referred as a SIP package which stands for single inline package.

It would be best to mount it this way but if design did absolutely not permit for this then you could probably lay long rectangular pads on a PCB and mount like a SMD component. Beware you may have to de-rate the thermal properties of the IC as it was likely tested while through-hole mounted. You could always use a header but that would only be warranted if you felt you would need to replace or change this component often.
